Replacement Parts List
CF-19CDBAXVM (2006/11/20)
PART NO. DESCRIPTION Q'TY
E1 DL3U11530AAA
PCB, MAIN
RTL 1
E2 DL3U21530AAA
PCB, AUDIO
RTL 1
E3 DL3U31530AAA
PCB, IO
RTL 1
E4 DL3U11550BAA
PCB, PAD
RTL 1
E5 DL3U21550BAA PCB, SW RTL 1
E6 DL3U31550BAA PCB, LED-LEFT RTL 1
E7 DL3U41550BAA
PCB, PR
RTL 1
E8 DL3U61550BAA
PCB, LED-RIGHT
RTL 1
E9 DL3U71550BAA
PCB, SD
RTL 1
E10 DL3U81550BAA
PCB, HSDPA
RTL 1
E11 DL3U91550BAA
PCB, POWERSW
RTL 1
E12 DL3UP1552AAA
PCB, EXT ANT UNIT
RTL 1
E13 DL3UP1558BAA
PCB, BT 2.0 UNIT
RTL 1
E14 DL3UP1566AAA
BAT FPC UNIT
1
E15 DL3U11553AAA
WWAN MAIN ANT
1
E16 DL3U21553AAA
WWAN AUX ANT
1
E17 DL3U31553AAA
LAN-MAIN BT ANT
1
E18 DL3U41553AAA
LAN AUX ANT
1
E20 DFJS1060ZA WWAN COAXIAL CABLE 1
E21 DFJS1040YA
LCD CABLE DG
1
E22 S N0GB1J000018
INVERTER
1
E23 S N3CAYYY00012
HDD
1
E24 N2ABAJ000001 KEYBOARD US 1
E25 DFJS1061ZA MODEM JACK CABLE 1
E26 S N5HAZ0000014 MODEM 1
E27 N5ZZ00000119 PC2-4200 SODIMM 512M INFINEON 1
E28
DFJS1059ZA WLAN COAXIAL CABLE
1
E29 S N5HZC0000019
WIRELESS LAN MODULE
1
E30 D4CZY103A003
THERMISTOR
1
E31 DFJS1043ZA
POWER SW CABLE
1
E32 N2EABEC00006
TOUCHPAD
1
E33 BR-2330A/SF
LITHIUM COIN BATTERY
1
E34 DFJS1062ZB
LAN JACK CABLE
1
E35 K1NB94B00001
EXPRESS PCMCIA COMBO SLOT
1
E36 DFWV08A0092
LCD UNIT ASS'Y
1
E36-1 DL3DW0182BAA LCD ASS'Y 1
E36-1-1 A2CA00000056
LCD BACKLIGHT, CCFL
1
E36-1-2 DFHM0290ZA
REFLECTION ANGLE
1
E36-4 DFHR3D92YA LCD BACK DAMPER 1
E36-6 DFHR3596ZA
LCD BACK CUSHION DG CCFL
2
E36-7 DXHM0042ZA
SCREW
4
E36-9 DFHR3595ZA
LCD BACK CUSHION DG SIDE
3
E36-10 DFHR3B64ZA
LCD SIDE CUSHION A
2
E36-11 DFHR3506YA
LCD SIDE CUSHION C
2
E36-12 DFHR3507YA
LCD SIDE CUSHION D
1
E36-20 DFHR3798ZA
DIGITIZER SHEET
1
E36-21 DFHR3925ZA
LCD LIGHT SHIELD SHEET B
2
E36-22 DFHP7151ZA
ADHESIVE TAPE(PG SIDE)
3
Note : Important Safety Notice
Components identified by mark have special characteristics important for safety.
When replacing any of these components, use only manufacturer's specified parts.
Main Block Unit
REF. NO and AREA
!
