IC 600 C0ABZA000047 IC, AMP 1
IC 601 C0ABBA000093 IC, OP AMP 1
IC 602 C0DBAYY00194 IC, DC/DC 1
IC 603 C0JBAD000236 IC, LOGIC 1
IC 604 C0JBAB000622 IC, 1 GATE LOGIC 1
IC 605 C0DBEFH00002 IC, REGULATOR 1
IC 606 C0CBCAC00161 IC 1
IC 607 C0EBE0000333 IC 1
IC 608 C0DBDJH00009 IC, LINER 1
IC 610, 611, 612 C0DBALH00003 IC 3
L 1, 3 G1C1R0MA0076 INDUCTOR 2
L 2 G1C91NM00001 INDUCTOR 1
L 4, 906 J0JJC0000015 INDUCTOR 2
L 6, 11, 12, 18, 19, 20, 21,
25, 27
J0MAB0000200 INDUCTOR 9
L 7, 10, 26 J0JHC0000074 INDUCTOR 3
L 13, 14, 15, 24 J0JDC0000045 INDUCTOR 4
L 600 DDAZS100MT3T INDUCTOR 1
L 601 G1C100MA0106 INDUCTOR 1
L 602 G1CR56ZA0140 INDUCTOR 1
L 603 G1C2R8MA0022 INDUCTOR 1
L 605 G1C4R7MA0106 INDUCTOR 1
L 606 G1C4R7Z00013 INDUCTOR 1
L 607 G1A160H00001 INDUCTOR 1
PA 1, 2 S D4FB1R100009 SWITCH 2
Q 1, 2, 644, 802 B1CFGD000023 TRANSISTOR 4
Q 3, 22, 24, 36, 37, 607, 612 B1GBCFNN0042 TRANSISTOR 7
Q 4, 39 B1GDCFNN0031 TRANSISTOR 2
Q 5, 8 B1MBDCA00004 TRANSISTOR 2
Q 6, 13, 20, 29, 40, 641, 642,
643, 646, 801, 804
B1GBCFJN0037 TRANSISTOR 11
Q 9, 10, 11, 21, 26, 28, 31,
33, 625
B1DHDC000028 TRANSISTOR 9
Q 12, 14, 15, 17, 18, 19 B1MBBCA00003 TRANSISTOR 6
Q 25, 27, 32, 617, 618, 619,
621, 623, 626
XP0421300L TRANSISTOR 9
Q 30 B1DHFD000015 TRANSISTOR 1
Q 34, 35 B1CFFB000001 TRANSISTOR 2
Q 600, 601, 602 XP0421400L TRANSISTOR 3
Q 603, 604, 606 B1CHRD000001 TRANSISTOR 3
Q 608, 634, 638 B1CFGD000003 TRANSISTOR 3
Q 609, 610, 637 B1MBEDA00017 TRANSISTOR 3
Q 616, 622 B1CHRC000009 FET 2
Q 631, 633, 639, 640, 800 B1DBGD000006 TRANSISTOR 5
Q 632, 803 B1DFGD000032 TRANSISTOR 2
Q 645 B1MBEDA00008 TRANSISTOR 1
R 1, 2, 24, 25, 38, 42, 43,
140, 141, 179, 180, 281,
283, 305, 306, 437
ERJ2GEJ102X RESISTOR, 1/16W, 1K 16
R 3 D1H85104A024 RESISTOR ARRAY 1
R 7, 8, 28, 30, 36 ERJ2RKF1000X RESISTOR, 1/16W, 100 5
R 9, 676, 685 ERJ2RKF1001X RESISTOR, 1/16W, 1K 3
R 10 ERJ2RKF2001X RESISTOR, 1/16W, 2K 1
R 12 ERJ2RKF51R0X RESISTOR, 1/16W, 51 1
R 13, 15 ERJ2RKF27R4X RESISTOR, 1/16W, 27.4 2
R 14, 16, 31, 32 ERJ2RKF54R9X RESISTOR, 1/16W, 54.9 4
R 18 ERJ2RKF68R0X RESISTOR, 1/16W, 68 1
R 19, 21 ERJ2GEJ560X RESISTOR, 1/16W, 56 2
R 20, 636, 712, 731 ERJ3GEYJ100V RESISTOR, 1/16W, 10 4
