Main Specifications
Model No. CF-19CHBAXBM CF-19CDBAXVM
CPU
Intel
®
Core™ Duo Processor U2400 (1.06
GHz
, 2
MB
*1
L2 cache, 533
MHz
FSB)
Chipset Intel
®
945GM
Memory
*1*2
512
MB
(4096
MB
Max.)
Video Memory
*1*3
UMA (128
MB
Max.)
Hard Disk Drive
*4
80
GB
Display Method 10.4 XGA type (TFT)
Internal LCD
*5
65,536/16,777,216 colors (800 × 600 dots/1024 × 768 dots)
External Display
*6
65,536/16,777,216 colors (800 × 600 dots/1024 × 768 dots/1280 × 768 dots/1280 × 1024
dots)
Wireless LAN
*7
Bluetooth
TM
*8
LAN IEEE 802.3 10Base-T
Intel PRO / Wirelee 3945 ABG (802.11a + b + g)
2.0 + EDR
, IEEE 802.3u 100Base-TX
Modem
Data: 56
kbps
(V.92) FAX: 14.4
kbps
Sound WAVE and MIDI playback, Intel
®
High DeÞ nition Audio subsystem support, Monaural speaker
Security Chip TPM (TCG V1.2 compliant)
*9
Card Slot PC Card
Type I or Type II x 1 (3.3
V
: 400
mA
, 5
V
: 400
mA
)
ExpressCard ExpressCard/34
*10
or ExpressCard/54 x 1
SD Memory Card
*11
x 1, Data transfer rate = 8
MB
per second
*12
RAM Module Slot
200-pin, 1.8
V
, SO-DIMM, DDR2 SDRAM, PC2-4200 Compliant
Interface USB port (4-pin, USB 2.0) x 2, Serial Port (Dsub 9-pin male), Modem port (RJ-11), LAN port
(RJ-45), External display port (Mini Dsub 15-pin female), Expansion Bus Connector (Dedicated
100-pin female), External Antenna Connector (Dedicated 50 coaxial connector) x 2, IEEE
1394a Interface Connector (4-pin x 1), Microphone Jack (Miniature jack, 3.5 DIA, Stereo),
Headphone Jack (Miniature jack, 3.5 DIA, Impedance 32 , Output Power 4
mW
× 2)
Keyboard / Pointing Device 82 keys / Touch Pad / Touchscreen (Anti-
Reß ection, Stylus (included) touch capable)
82 keys / Touch Pad / Digitizer (Anti-Reß ec-
tion)
Power Supply AC adaptor or Battery pack
AC Adaptor
*13
Input: 100
V
to 240
V
AC, 50
Hz
/60
Hz
, Output: 16.0
V
DC, 3.75
A
Battery Pack
Li-ion 10.65
V
, 5.7
Ah
Operating Time
*14
Approx. 4.5 hours to 8 hours
*15
(Approx. 7 hours
*16
)
Charging
Time
*14
Power on Approx. 7.5 hours
Power off Approx. 4.5 hours
Clock Battery
Coin type lithium battery 3.0
V
Power Consumption
*17
Approx. 26
W
*18
/ Approx. 55
W
(Maximum when recharging in the ON state)
Physical Dimensions (W × H × D)
(excluding the hand strap/shoul-
der strap)
271
mm
× 49
mm
× 216
mm
{10.7" × 1.93" × 8.5"}
Weight
(excluding the hand strap/shoul-
der strap)
Approx. 2.25
kg
{Approx. 4.96
lb.
} Approx. 2.30
kg
{Approx. 5.07
lb.
}
Operation Environment
Temperature: 5
°C
to 35
°C
{41
°F
to 95
°F
}
Humidity: 30
%
to 80
%
RH (No condensation)
Storage Environment
Temperature: -20
°C
to 60
°C
{-4
°F
to 140
°F
}
Humidity: 30
%
to 90
%
RH (No condensation)
1 Specifications
1-1
