– 87 –
Chapter 10 Menu Operations — Menu list
Item Description of settings
[SDI OUT] [P to PsF] Sets the segment frame for the output from terminals <SDI OUT1> to <SDI OUT4>.
This is enabled only when both of the following items are set.
f When [MENU] → [SYSTEM SETTINGS] → [SYSTEM MODE] → [FREQUENCY] is set to [29.97p],
[23.98p], or [25.00p].
f When [MENU] → [SYSTEM SETTINGS] → [SYSTEM MODE] → [PIXEL] is set to [1920×1080].
[ON], [OFF]
f Factory setting: [OFF]
[4K OUT TYPE] Sets the 4K signal format to be output from terminals <SDI OUT1> to <SDI OUT4>.
[SQUARE], [2 SAMPLE INT]
f Factory setting: [SQUARE]
[3G-SDI OUT] Sets the 3G SDI signal format to be output from terminals <SDI OUT1> to <SDI OUT4>.
[LEVEL-A]: Selects the LEVEL-A method.
[LEVEL-B]: Selects the LEVEL-B DL method.
f Factory setting: [LEVEL-B]
[SDI REC REMOTE] Sets whether to use the control function of recording operation for an external device (such as a recorder)
connected to the <SDI OUT> terminal.
[ON]: Controls the recording operation of the external device.
[OFF]: Does not control the recording operation of the external device.
f Factory setting: [OFF]
[MON OUT] [1080p to 1080i] Selects whether to convert the output signal from the <MON OUT1> terminal and <MON OUT2> terminal
to 1080i when in 1080P mode.
[ON], [OFF]
f Factory setting: [OFF]
[3G-SDI OUT] Sets the 3G SDI signal format to be output from the <MON OUT1> terminal and <MON OUT2> terminal.
[LEVEL-A]: Selects the LEVEL-A method.
[LEVEL-B]: Selects the LEVEL-B DL method.
f Factory setting: [LEVEL-B]
[MON OUT2 SIGNAL
SEL]
Sets the output from the <MON OUT2> terminal.
[VF]: Selects the same output as the <VF SDI> terminal.
[MON OUT1]: Selects the same output as the <MON OUT1> terminal.
f Factory setting: [VF]
[MON OUT1 STATUS] Sets whether to show the status display on the output from the <MON OUT1> terminal.
[ON], [OFF]
f Factory setting: [OFF]
[MON OUT2 STATUS] Sets whether to show the status display on the output from the <MON OUT2> terminal.
[ON], [OFF]
f Factory setting: [OFF]
[MENU DISP] Sets whether to display [MENU] in the output from the <MON OUT1> terminal and <MON OUT2> terminal.
[ON], [OFF]
f Factory setting: [ON]
[MON OUT INDICATOR] [SYSTEM PIXEL] Displays/hides system pixels.
[ON], [OFF]
f Factory setting: [ON]
[SYSTEM FREQ] Displays/hides system frequency.
[ON], [OFF]
f Factory setting: [ON]
[REC FORMAT] Displays/hides recording format display.
[ON], [OFF]
f Factory setting: [ON]
[FPS] Displays/hides frame rate.
[ON], [OFF]
f Factory setting: [ON]
[SHUTTER] Displays/hides shutter speed.
[ON], [OFF]
f Factory setting: [ON]
[EI] Displays/hides EXPOSURE INDEX.
[ON], [OFF]
f Factory setting: [ON]
[WHITE] Displays/hides color temperature.
[ON], [OFF]
f Factory setting: [ON]
[IRIS] Displays/hides iris value.
[ON], [OFF]
f Factory setting: [ON]
[FOCUS] Displays/hides focus distance.
[ON], [OFF]
f Factory setting: [ON]
[ZOOM] Displays/hides zoom value.
[ON], [OFF]
f Factory setting: [ON]
[FILTER] Displays/hides the optical lter transmittance.
[ON], [OFF]
f Factory setting: [ON]
