– 92 –
Chapter 10 Menu Operations — Menu list
Item Description of settings
[SHOCKLESS WHITE]
Sets the transition time when switching preset values.
[OFF]: Values are immediately switched.
[1]: Switches in approximately one second.
[2]: Switches in approximately two seconds.
[3]: Switches in approximately ve seconds.
f Factory setting: [OFF]
[BLACK]
[ABB] Executes automatic black balancing. When executing automatic black balancing, put the cap on the lens to
keep any light from entering the image sensor.
[EXECUTE], [CANCEL]
f Factory setting: [CANCEL]
[M.PED]
Sets the master pedestal level.
[100]…[100]
f Factory setting: [0]
[R PED]
Adjusts the Rch pedestal level.
[100]…[100]
f Factory setting: [0]
[G PED]
Adjusts the Gch pedestal level.
[100]…[100]
f Factory setting: [0]
[B PED]
Adjusts the Bch pedestal level.
[100]…[100]
f Factory setting: [0]
[ABB OFFSET]
Sets the Rch, Gch, and Bch pedestal levels after adjusting the automatic black balance.
[ON]: Maintains and adds the values of [R PED], [G PED], and [B PED] after performing the automatic
black balance.
[OFF]: Resets the values of [R PED], [G PED], and [B PED] after performing the automatic black balance.
f Factory setting: [OFF]
[EI] [MODE] Switches the EXPOSURE INDEX control unit.
[ISO], [dB]
f Factory setting: [ISO]
[SETTING(ISO)] Sets the value when [ISO] is selected.
[800], [1000], [1250], [1600], [2000], [2500], [3200], [4000], [5000], [6400], [8000], [10000], [12800]
f Factory setting: [800]
[SETTING(GAIN)] Sets the value when [dB] is selected.
[0dB], [3dB], [6dB], [9dB], [12dB], [15dB], [18dB], [21dB], [24dB]
f Factory setting: [0dB]
[GAIN OFFSET SW]
Sets whether to perform ne adjustment of control when [dB] is selected.
[ON], [OFF]
f Factory setting: [OFF]
[OFFSET LEVEL]
Sets the ne adjustment level.
[0.0dB] - [3.0dB] (0.1 dB step)
f Factory setting: [0dB]
[SHUTTER] [SW] Enables/disables the shutter function.
[ON], [OFF]
f Factory setting: [ON]
[DISPLAY MODE] Sets the shutter display unit.
[sec]: Displays in time.
[deg]: Displays at shutter open angle.
f Factory setting: [deg]
[MODE] Switches the shutter control mode.
[PRESET]: Selects the mode from 12 modes inside the memory.
[SYNCHRO]: Selects the mode from the operable range.
f Factory setting: [PRESET]
[SYNCHRO deg] Sets the value of angle control ([deg]).
[1.0] - [360.0]
f Factory setting: [180.0]
[SYNCHRO sec] Sets the value of time control ([sec]). The lowest value changes depending on the frame rate ([FPS]) value.
[1/60] - [1/250]
f Factory setting: [1/48]
[PRESET VALUE deg] Selects the angle control ([deg]) value from the maximum of 12 values set in the control panel.
Preset values that can be selected in the factory setting are [11.5], [22.5], [45.0], [90.0], [120.0], [144.0],
[172.8], [180.0], [270.0], and [360.0].
f Factory setting: [180.0]
[PRESET VALUE sec] Selects the time control ([sec]) value from the maximum of 12 values set in the control panel.
Preset values that can be selected in the factory setting are [1/60], [1/100], [1/120], [1/250], [1/500],
[1/1000], and [1/2000].
f Factory setting: [1/60]
[TEST SIG]
[TEST SIG SEL] Sets the test signal output.
[OFF]: Does not output a test signal.
[BARS]: Outputs the color bar set in [COLOR BARS TYPE].
f Factory setting: [OFF]
[COLOR BARS TYPE]
Set the color bar to be used.
[SMPTE]: Uses the color bar in the SMPTE standard.
[FULL]: Uses full color bars.
f Factory setting: [FULL]
