Installation Requirements 1-2
II L 00
1.4 Tools Required
Table 1.2 Tools Required
Item Name Usage
1 Cutter Unpacking
2 Phillips Screw Driver NO.2 shaft
length; approx. 40 and 100mm
Removing and installing the screw for covers
3 Adjustable Open End Wrench Leveling the bolt
Fixing the leveling the bolts
4 Level Meter Installation the Container Stacker
1.5 Environmental Conditions
Table 1.3 Environmental Conditions
Items Value
Temperature 10 ~32 °C (50 ~ 89.6°F)
Humidity 20 ~80 %RH
(Wet Bulb 26 °C (78.8 °F ) max.)
Altitude 0 to 2,100 m (0 to 7,000 feet) max.
1.6 Input Line Voltage
Table 1.4 Print Engine Input Line Voltage
Input Line Voltage AC 200V ~ AC 240V
Phase Single Phase, two wires and grounding wire
Frequency 50/60 Hz ±1Hz
Transient (Static) ±10%
Transient (Dynamic) –18% / +15% 500ms
Drop out -100%, 20ms
II L 01
