Full Duplex Intercom
125
7" Modero Widescreen Touch Panels
Answering an incoming call
The provided intercom pages include an answering popup window. The popup page indicates the name
of the panel calling and two options:
Answer - Pressing this button opens the intercom session with the other panel.
Ignore - Pressing this button denies the intercom session with the other panel.
To answer a call:
In the popup window, press the Answer button.
Sample Intercom Page (Cont.)
No. Name Description Channel
Port:Code
Address
Port:Code
Level
Port:Code
24 Monitor Panel Display only; indicates the
panel is being monitored by
another panel.
1:29
25 Monitor Panel Display only; indicates the
panel is being monitored by
another panel.
1:32
26 Monitor Panel Display only; indicates the
panel is being monitored by
another panel.
1:35
27 Intercom Microphone Level A Bargraph in TPDesign4 that
sets the volume of the intercom
microphone.
0:10
28 Intercom Sound Level A Bargraph in TPDesign4 that
sets the volume of the intercom
speaker.
0:9
29
Call Status Button Displays status of calls, e.g.,
incoming caller id,
connected, rejected.
1:10
30 Navigate Up Increments the intercom
directory up.
1:13
31 Navigate Down Increments the intercom
directory down.
1:14
32 Intercom Setup Page Navigates the intercom panel
to the intercom Setup page.
This requires a standard page
flip to Setup.
FIG. 95
Answer Call
