Firmware Pages and Descriptions
68
7" Modero Widescreen Touch Panels
Panel Information Page Elements (Cont.)
Panel Type: Displays the model of the Modero panel being used.
Firmware Version: Displays the G4 firmware version being used by the panel.
• Verify you have the latest version from www.amx.com.
Setup Port: Displays the setup port information/value being used by the panel.
High Port: Displays the high port (port count) value for the panel.
High Address: Displays the high address (address count) value for the panel.
High Channel: Displays the high channel (channel count) value for the panel.
High Level: Displays the high level (level count) value being used by the panel.
Serial Number: Displays the specific serial number value assigned to the panel.
Setup Pages Version: Displays the type and version of the Setup pages being used by the panel.
Screen Width: Displays the pixel width being used to display the incoming video signal on the
Modero panel.
• Maximum available screen width on a NXD-700Vi Modero panel is 800 pixels.
Screen Height: Displays the pixel height being used to display the incoming video signal on the
Modero panel.
• Maximum available screen height on a NXD-700Vi Modero panel is 480
pixels.
Screen Refresh Rate: Displays the video refresh rate applied to the incoming video signal from the
panel. Default rate is 60.
Screen Rotation: Displays the degree of rotation applied to the on-screen image.
Power Up Pages: Displays the first touch panel page assigned for display after the device is
powered-up.
• This information is taken from the TPD4 project file.
• Most projects begin with a Main page.
Start Up String: Displays the start-up string.
Wake Up String: Displays the wake up string used after an activation from a timeout.
Sleep String: Displays the sleep string used during a panel’s sleep mode.
File System: Displays the amount of Compact Flash memory available on the Modero panel.
RAM: Displays the available RAM (or Extended Memory module) on the Modero
panel.
