Firmware Pages and Descriptions
70
7" Modero Widescreen Touch Panels
Volume Page
The Volume page (FIG. 59) (accessed by pressing the Audio Adjustments button on the Setup page)
allows you to adjust the master volume parameters and default panel sounds on the panel.
The elements of the Volume page are described in the table below:
Time & Date Setup Page (Cont.)
Set Date/Time: Use the UP/DN arrow buttons to adjust the Master’s calendar date and time. The
blue icon indicates which field is currently selected (see FIG. 58).
• Year range = 2000 - 2037
• Month range = 1 - 12
• Day range = 1 - 31
• Hour = 24-hour military
• Minute range = 0 - 59
• Second range = 0 - 59
FIG. 59
Volume configuration page
Volume Page Elements
Back: Saves the changes and returns you to the previously active touch panel page.
Connection Status icon: This visual display of the connection status allows the user to have a current
visual update of the panel’s connection status regardless of what page is
currently active.
• A Lock only appears on the icon if the panel has established a connection
with a currently secured target Master (requiring a username and password).
Master Volume: This section allows you to alter the current master volume level:
• Use the UP/DN buttons to adjust the volume level (range = 0 - 100).
• The Master Volume bargraph indicates the current volume level.
• The Mute button toggles the Mute feature.
Default = 50
