7" Modero Widescreen Touch Panels
Input Commands
These Send Commands are case insensitive.
Input Commands
^CAL
Put panel in
calibration mode.
Syntax:
"'^CAL'"
Example:
SEND COMMAND Panel,"'^CAL'"
Puts the panel in calibration mode.
^KPS
Set the
keyboard
passthru.
Syntax:
"'^KPS-<pass data>'"
Variable:
pass data:
<blank/empty> = Disables the keyboard.
0 = Pass data to G4 application (default). This can be used with VPC or text areas.
1 - 4 = Not used.
5 = Sends out data to the Master.
Example:
SEND COMMAND Panel,"'^KPS-5'"
Sets the keyboard passthru to the Master. Option 5 sends keystrokes directly to the
Master via the Send Output String mechanism. This process sends a virtual keystroke
command (^VKS) to the Master.
Example 2:
SEND COMMAND Panel,"'^KPS-0'"
Disables the keyboard passthru to the Master.
The following point defines how the parameters within this command work:
• Accepts keystrokes from any of these sources: attached USB keyboard or Virtual
keyboard.
^MBT
Set the mouse
button mode for
the virtual PC.
Syntax:
"'^MBT-<0-3>'"
Variable:
0 = None.
1 = Left.
2 = Middle.
3 = Right.
Example:
SEND COMMAND Panel,"'^MBT-1'"
Sets the mouse button mode for the virtual PC to LEFT.
^MDC
Set the mouse
double click ON
for the virtual PC.
Syntax:
"'^MDC'"
Example:
SEND COMMAND Panel,"'^MDC'"
Enables the double click for the virtual PC.
