Programming
136
7" Modero Widescreen Touch Panels
Border styles and Programming numbers
Border styles can be used to program borders on buttons, sliders, and popup pages.
The TPDesign4 Touch Panel Design program has pre-set border styles that are user selectable.
You cannot use the following number values for programming purposes when changing border styles.
TPD4 border styles can ONLY be changed by using the name.
Border Styles and Programming Numbers
No. Border styles No. Border styles
0-1 No border 10-11 Picture frame
2 Single line 12 Double line
3 Double line 20 Bevel-S
4 Quad line 21 Bevel-M
5-6 Circle 15 22-23 Circle 15
7 Single line 24-27 Neon inactive-S
8 Double line 40-41 Diamond 55
9 Quad line
TPD4 Border Styles by Name
No. Border styles No. Border styles
1 None 22 Circle 155
2 AMX Elite -L 23 Circle 165
3 AMX Elite -M 24 Circle 175
4 AMX Elite -S 25 Circle 185
5 Bevel -L 26 Circle 195
6 Bevel -M 27 Cursor Bottom
7 Bevel -S 28 Cursor Bottom with Hole
8 Circle 15 29 Cursor Top
9 Circle 25 30 Cursor Top with Hole
10 Circle 35 31 Cursor Left
11 Circle 45 32 Cursor Left with Hole
12 Circle 55 33 Cursor Right
13 Circle 65 34 Cursor Right with Hole
14 Circle 75 35 Custom Frame
15 Circle 85 36 Diamond 15
16 Circle 95 37 Diamond 25
17 Circle 105 38 Diamond 35
18 Circle 115 39 Diamond 45
19 Circle 125 40 Diamond 55
20 Circle 135 41 Diamond 65
21 Circle 145 42 Diamond 75
