4.
Open the print cartridge box and
container, then grasp the print car`
tridge by the green top and remove the
cartridge from the container. Gently
remove both
pieces of tape`blue and
white`covering the ink nozzles and
vent hole.
CAUTIONS:
1) If you don't remove
the white tape, you deplete the ink in
the cartridge prematurely. 2) Be care`
ful not to touch the ink nozzles or the
copper contacts. Fingerprints may
damage them.
Remove
both
pieces of tape!
5.
Place the print cartridge down into the
cradle as shown. Align the green
arrow on the cartridge top with the
green dot on top of the cradle.
sl-42
6.
Push the green arrow toward the green
dot until the cartridge
snaps
into
place.
sl-43
7.
Close the top cover, then close the
front panel.
Be sure to close the front panel
firmly
, until both corners snap into
place.
sl-30b
