Chapter 13
Port Security
This section describes the Port Security feature.
Overview
Port Security:
Allows for limiting the number of MAC addresses on a given port
Packets that have a matching MAC address (secure packets) are forwarded; all other packets
(unsecure packets) are restricted
Enabled on a per port basis
When locked, only packets with allowable MAC address will be forwarded
Supports both dynamic and static
Implement two traffic filtering methods
Dynamic Locking - User specifies the maximum number of MAC addresses that can be
learned on a port. The maximum number of MAC addresses is platform dependent and is
given in the software Release Notes. After the limit is reached, additional MAC addresses
are not learned. Only frames with an allowable source MAC address are forwarded.
Static Locking - User manually specifies a list of static MAC addresses for a port.
Dynamically locked addresses can be converted to statically locked addresses.
These methods can be used concurrently
