–Index
This tag contains the site index that allows direct access to any of the pages under the
main tags and sub tags.
Sub Tags
The sub tag content changes depending on the selected main tag. In turn, each sub tag
provides further sub categories of functions.
2. Unified Web Control Buttons
Depending on the selected main tag and sub tag, in the lower right corner, there are buttons
that enable you to perform various page-dependent operations:
•Add
Add a new class, group, ACL, or VLAN.
•Apply
Apply all changes that you made to a page.
Cancel
Cancel all changes that you made to a page.
•Delete
Delete an existing list or group that was created by using an Add operation.
Refresh
Refresh the data on the page such as log entry, port statistics, and other data.
3. Index Page
One of the unique features of the PCC is the Index page. This page provides links to all
available pages on the PCC, allowing you to connect to each page directly. On the Index page,
you can use your Web browser’s search function to locate a particular feature, and then
connect directly to the page that enables you to view or configure that feature. Note that when
you access a page directly from the Index page, the navigation pane does not adjust as it
normally would when you navigate to the page by using a main tag and sub tag.
4. Save the Configuration
When you click the Apply button to save the changes, the changes are applied to the switch but
not saved into the permanent memory of the switch. When you reboot the switch, the changes
are lost.To save the changes into the permanent memory of the switch, use the Save
Configuration function that you can reach by clicking on the Maintenance tag and then on the
Save Config tag.
