NETGEAR 7000 Series Managed Switch Administration Guide Version 7.2
6-2 Link Aggregation
v1.0, May 2008
Figure 6-1 shows the example network.
Example #1: Create two LAGS
Use the show port-channel all command to show the logical interface ids you will use to identify
the LAGs in subsequent commands. Assume that lag_10 is assigned id 1/1/1 and lag_20 is
assigned id 1/1/2.
Figure 6-1
(Netgear Switch) #config
(Netgear Switch) (Config)#port-channel lag_10
(Netgear Switch) (Config)#port-channel lag_20
(Netgear Switch) (Config)#exit
(Console) #show port-channel all
Port- Link
Log. Channel Adm. Trap STP Mbr Port Port
Intf Name Link Mode Mode Mode Type Ports Speed Active
------ --------------- ------ ---- ---- ------ ------- ------ --------- ------
1/1/1 lag_10 Down En. En. Dis. Dynamic
1/1/2 lag_20 Down En. En. Dis. Dynamic
