PTM 2-28 B070/B071
2.3.6 RELATION BETWEEN THE SP AND UP SETTINGS
The tables below illustrate the relationship between the UP and SP settings for each
of the 5 original modes. The scale across the top of the table is the range of settings
for the SP modes.
The settings in the gray areas indicate the UP settings overlaid on the SP scale of the
table. Words that are not shaded within the tables, such as ‘softer’, indicate how the
image changes if you change the SP setting is a certain direction. The related UP
mode is User Tools> Copier Features> General Features> Copy Quality.
Text Mode
Setting 0 1 2 3 4 5 6 7 8 9 10 SP No.
25% ~55% SP4903 001
55.5 ~ 75% SP4903 002
75.5 ~ 160% SP4903 003
160.5 ~ 400%
Soft
Normal
Sharp
SP4903 004
Photo Mode (Dithering)
Setting 0 1 2 3 4 5 6 SP No.
25% ~55% SP4903 005
55.5 ~ 75% SP4903 006
75.5 ~ 160% SP4903 007
160.5 ~ 400%
Softer
Print Photo
Sharper
SP4903 008
Photo Mode (Error Diffusion)
Setting 0 1 2 3 4 5 6 SP No.
25% ~55% SP4903 009
55.5 ~ 75% SP4903 010
75.5 ~ 160% SP4903 011
160.5 ~ 400%
Softer
Normal
Glossy Photo
Sharper
SP4903 012
