2. LPS options
There are many options available for your Xerox 4635 Laser
Printing System (LPS) which offer a wide range of enhanced
printing and communications capabilities. This chapter provides
a brief overview of the options for the following:
• System controller options
• Printer options
• Printer configurations
• Graphics
• Host resident software packages.
For detailed information regarding these options, contact your
customer support representative.
System controller options
The following interface and system disk options are available for
your Xerox 4635 Laser Printing System (LPS) system controller.
Interface options
Your laser printing system may be configured for either the
online interface, the offline interface, or both (switchable). HIP
(host interface processor)-accessed interfaces are also available.
Online interface
The online (channel-attached) interface receives input directly
from any environment that supports the IBM 3211 and 4245 host
systems.
Offline interfaces
The offline interface is an excellent alternative or addition to an
online operation. It supports:
• 9-track magnetic tapes
• 18-track cartridge tapes.
The 9-track magnetic and 18-track cartridge tape drives are
housed in a peripheral cabinet, as shown in figure 2-1.
XEROX 4635 LASER PRINTING SYSTEM INSTALLATION PLANNING GUIDE 2-1
