INSTALLATION
Customer responsibilities
Customer responsibilities include the following:
• Ensure that all needed supplies are on site.
• Ensure that your system specialist is available during the
loading of software and applications tapes.
• Have the appropriate operators available for training.
• Check the documentation and software kits for
completeness.
• Have test jobs ready to run, if desired.
Note: If the customer has elected to use the LAN capability to
upload audit logs to a remote system they are responsible for the
following:
• Providing a LAN PWB plus all associated cables that meets
the following requirements to the service rep for installation
into the PCUI:
••ethernet or token ring interface
•• software configurable or plug and play
•• FCC class B
•• UL standard 478 with a fire rating of 94V0 or 94V1
•• UL standard 1950
• Providing the log destination drive name and subdirectory to
the service rep for system configuration.
• Connecting the LAN cable to the network.
• Loading the LAN PWB software.
• Operation and maintenance of the LAN including the LAN
PWB installed in the PCUI.
4-2 XEROX 4635 LASER PRINTING SYSTEM INSTALLATION PLANNING GUIDE
