PREINSTALLATION
Figure 3-9 shows the minimum service space required between
two 4635 printers positioned face-to-face. The printers should
be separated by at least 74 inches/1880 mm. This allows enough
space for the front panels of one printer to be opened, without
obstructing the 24 inch/610 mm operator area of the other
printer.
Figure 3-9. Face-to-face shared service area space
When determining your space requirements and planning for
shared space between your LPS, it is important to consider all the
components you plan to have installed. If you have an optional
bypass transport or input enablement device on your 4635 LPS,
you need to consider the size and configuration of the finishers
and feeders you purchase. A finisher can add considerable
length to your LPS and possibly consume space in front of your
LPS. Your feeder may require a large amount of space behind
your LPS.
The 36-inch/914-mm clearance space around each component
must be observed for your feeders and finishers, therefore, must
be considered when planning configuration of your systems. To
ensure all the space requirements are met, it is important to work
with your Xerox or Rank Xerox representatives, as well as the
representatives of the company from which you have purchased
your finishers and feeders.
XEROX 4635 LASER PRINTING SYSTEM INSTALLATION PLANNING GUIDE 3-9
