PREINSTALLATION
over 250 standard 300 spi fonts, referred to as the A03 font
family.
Licensed fonts In addition to the library of standard fonts delivered with your
LPS, over 100 licensed fonts may be ordered from the Xerox Font
Center.
Custom fonts Custom fonts and graphic images such as company logos and
signatures can be digitized by the Xerox Font Center for use on
your LPS.
Receiving fonts The fonts provided by the Xerox Font Center are contained on 9-
track tape, 18-track cartridges, or 1/4-inch cartridges. One tape
may contain several fonts, each of which is a separate file. Fonts
may also be sent to the LPS from an online host computer
through an IBM-compatible channel.
As with the other initial supplies, your Xerox or Rank Xerox sales
representative will assist you with determining your LPS fonts
needs for installation. After installation, the Xerox Font Center
can help you order additional licensed and custom fonts. (Refer
to the “Xerox Font Center” section of the “Postinstallation“
chapter )
Paper
You need to select your paper carefully; without the proper
paper, you increase the probability of paper jams and misfeeds.
Your LPS can print on standard white, colored, predrilled, and
preprinted (that is, letterhead and forms) paper, labels, and
transparencies. They must meet the specifications set forth by
Xerox for operability in the LPS. Additional information about
paper for your LPS can be found in your LPS operator guide.
Use a good quality xerographic grade paper. For best results,
use 20-pound/75 gsm bond xerographic grade paper. Xerox
papers are specifically designed for optimal performance in your
laser printing system. (Refer to the consumable supplies table at
the end of chapter 5.)
Use paper within these parameters:
Lightest: 16-pound/60-gsm (grams per square meter)
Heaviest: 110-pound/200-gsm
The 4635 accepts paper sizes as small as 7 by 10 inches/187 mm
by 254 mm, with the optional 7X10 enablement kit. Larger paper
sizes, such as 11 by 17 inches/297 by 432 mm, A3 (297 by 420
mm/11.69 by 16.54 inches) and B4 (257 by 364 mm/10.12 by
14.33 inches), can also be fed.
Paper has a tendency to curl under the heat that is present inside
xerographic equipment. Paper with low moisture content curls
less. Paper with excessive moisture content has a tendency to
jam because of the greater curl.
Note: The maximum recommended moisture content is 5.7
percent.
Paper is fed into the LPS with the long side as the leading edge.
(A3 and 11- by 17-inch paper sizes are fed short edge first.) The
3-24 XEROX 4635 LASER PRINTING SYSTEM INSTALLATION PLANNING GUIDE
