PREINSTALLATION
Environmental/electrical requirements
Your 4635 LPS has important environmental and electrical
requirements that must be accommodated. These requirements
are summarized in the table below. For further details on
electrical requirements, refer to the following voltage charts and
wiring diagrams.
Table 3-6. 4635 environmental and electrical requirements
Environmental requirements
Operating temperature Recommended: 74° F ± 4° F/24° C ± 4° C
Minimum: 54° F/14° C
Maximum: 85° F/29° C
Humidity Recommended: 45% ± 10%
Minimum: 15%
Maximum: 85%
Altitude Normal: Up to 6,000 feet/1830 m above sea
level
Maximum: 9,000 feet/2743 m above sea level
Heat dissipation
System controller 3,754 Btu per hour
Peripheral cabinet (fully configured) 3,195 Btu per hour
Printer Operating: 28,140 Btu per hour
Standby: 4,454 Btu per hour
(fuser on)
Energy Saver: 2,7000 Btu per hour
System controller U.S. and Canada, 60 Hz:
208/240 VAC (1 phase) or 208/220
VAC (Line 1 to Line 2);
15 amp service
NEMA 6-15R or ANSI C73, 20R
KVA 1.1 (operating)
International, 50 Hz:
200/230 VAC (1 phase)
15 amp service;
Power connector per local codes
Printer U.S. and Canada, 60 Hz:
120/240 VAC or 120/208 VAC;
50 amp service;
NEMA 14-50R
KVA 7.3 (operating)
International, 50 Hz (WYE):
380, 400, 415 VAC (3 phase, 5 wire);
20 amp service (WYE)
International, 50 Hz (DELTA):
220, 230, 240 VAC (3 phase, 4 wire);
30 amp service (DELTA)
XEROX 4635 LASER PRINTING SYSTEM INSTALLATION PLANNING GUIDE 3-15
