PREINSTALLATION
Finishing and feeding equipment
It is important to note that while the Bypass Transport and Input
Enablement options provide you with an interface between your
4635 LPS and your finishing and feeding accessories, they require
their own AC and DC power sources. The power must be
independent of your 4635 LPS.
Consult your Xerox or Rank Xerox sales representative, as well as
the sales representative of the company from which you
purchased your finishing and feeding equipment, for specific
electrical and space requirements.
Interface requirements
Channel-attached
For an online configuration with an IBM host system, the
following cables must be available:
• Bus and tag cables (bus in, bus out, tag in, tag out)
• Emergency power off (EPO) cable (optional)
• Terminators (if necessary, due to location on channel).
For your convenience, it is possible to order the Bus and Tag
cables for the printer through Xerox Corporation on a purchase-
only basis. Contact your Xerox or Rank Xerox sales
representative for current pricing and order information.
Third party connections
Xerox supports a number of third party connections. For more
information, contact your Xerox or Rank Xerox sales
representative or call the Xerox Connection between 7 a.m. and
4 p.m. Pacific time at:
1-800-451-9312 (continental U.S.)
XEROX 4635 LASER PRINTING SYSTEM INSTALLATION PLANNING GUIDE 3-21
