PREINSTALLATION
Table 3-1. Turning radius for printer (not separated)
Passage or doorway A width Minimum passage B width
29 inches/737 mm 83 inches/2108 mm
30 inches/762 mm 76 inches/1930 mm
31 inches/787 mm 73 inches/1854 mm
32 inches/813 mm 70.5 inches/1791 mm
34 inches/864 mm 66.5 inches/1690 mm
36 inches/914 mm 63.5 inches/1613 mm
38 inches/965 mm 61.5 inches/1562 mm
40 inches/1016 mm 58 inches/1473 mm
42 inches/1067 mm 55 inches/1397 mm
Table 3-2. Turning radius for printer (separated from PHM)
Passage or doorway A width Minimum passage B width
29 inches/737 mm 74.5 inches/1892 mm
30 inches/762 mm 64.5 inches/1638 mm
31 inches/787 mm 62 inches/1575 mm
32 inches/813 mm 59.5 inches/1511 mm
34 inches/864 mm 56 inches/1422 mm
36 inches/914 mm 53 inches/1346 mm
38 inches/965 mm 50 inches/1270 mm
40 inches/1016 mm 48 inches/1219 mm
42 inches/1067 mm 45.5 inches/1156 mm
Table 3-3. Turning radius for printer (separated and
upended on dolly)
Passage or doorway A width Minimum passage B width
30 inches/762 mm 49 inches/1245 mm
31 inches/787 mm 43 inches/1092 mm
32 inches/813 mm 41 inches/1041 mm
34 inches/864 mm 37.5 inches/953 mm
36 inches/914 mm 35 inches/889 mm
38 inches/965 mm 33.5 inches/851 mm
40 inches/1016 mm 32 inches/813 mm
42 inches/1067 mm 31 inches/787 mm
XEROX 4635 LASER PRINTING SYSTEM INSTALLATION PLANNING GUIDE 3-13
