12. Advanced Settings
A slider bar appears. Adjust with the ↑ or ↓ until there is no blue noise visible in the black areas.
Advanced Settings
Gamma
Color Temperature
Input Balance
Noise Reduction
Film mode detection [ON]
Video AGC
Display Settings
Installation
Service
Back
Menu 12-8
Input Balance
Black balance
White balance
Back
Menu 12-9
Black Balance
Black balance red
Black balance blue
Back
Menu 12-10
White balance
1. Select Advanced Settings .
2. Press ENTER to activate.
The Advanced Settings menu will be displayed. (menu 12-11)
3. Select Input Balance.
The Input Balance selection menu will be displayed. (menu 12-12)
4. Select White balance and press ENTER to activate.
The white balance menu will be displayed. (menu 12-13)
5. Adjust the Contrast to a maximum value until the green noise becomes visible in the white areas and return one step.
6. Select White balance red and press ENTER.
A slider bar appears. Adjust with the ↑ or ↓ until there the red noise becomes visible in the white areas and return one step.
7. Select Whitebalanceblueand press ENTER.
A slider bar appears. Adjust with the ↑ or ↓ until there the blue noise becomes visible in the white areas and return one step.
Advanced Settings
Gamma
Color Temperature
Input Balance
Noise Reduction
Film mode detection [ON]
Video AGC
Display Settings
Installation
Service
Back
Menu 12-11
Input Balance
Black balance
White balance
Back
Menu 12-12
White Balance
White balance red
White balance blue
Back
Menu 12-13
12.5 Noise Reduction
About Noise reduction
Reduces noise and pixel jitter in all video sources.
Noise reduction can be done manually or automatic. When set to automatic, the processor itself selects the best noise reduction
level for the actual displayed image.
Switching between manual and automatic
1. Select Advanced Settings .
2. Press ENTER to activate.
The Advanced Settings menu will be displayed. (menu 12-14)
3. Select Noise Reduction.
The noise reduction menu will be displayed. (menu 12-15)
4. Select Manually or Automatic and press ENTER to toggle between [Manually] or [Automatic].
68
R5976672 SOLARIS LC40 13/01/2005
