MFC SETUP AND CONNECTIONS
2-10
4
Carefully remove the sticker and transparent tape that covers
the copper print head.
Do NOT touch or
remove the copper
contact area!
Each ink cartridge has its own correct position. The Color ink
cartridge must be in the left-slot and the Black (or Photo)
cartridge must be in the right-slot. Match the color
indicators on the ink cartridge and the cartridge carrier.
5
Insert the new starter Color ink cartridge into the left-slot,
and press backward until it snaps.
If you have purchased the Photo ink cartridge accessory and
want to use it now, you can choose to install the Photo ink
cartridge in the right-slot.
6
Repeat Steps 3–5 to install the new starter Black (or Photo)
ink cartridge in the right-slot.
If the ink cartridges move loosely in the carrier, they are not
locked into place, so repeat Steps 5 and 6.
7
Close the cover.
DID YOU CHANGE?
RIGHT:1.YES 2.NO
8
Press
1
if you changed the right-side cartridge.
