B-5
Printer and Paper Specifications
Paper Specifications
Print Area
This section illustrates the recommended print area for single sheets and continuous forms.
May be decreased
to 4.23 mm
(1/6 inch).
However, line
spacing may be
uneven.
May be decreased to
8.5 mm
(1/3 inch).
However, line spacing
may be uneven.
Print area may be off
the paper, depending
on paper setting or
width.
25.4 mm (1 inch)
25.4 mm (1 inch)
Print area
5.08 mm or more
(0.2 inch or more)
H
H
H
H
Ws
Hs
Ls
Print Area for Single Sheets
LA36N LA36W
Ws 102 to 267 mm (4 to 10.5 in) 102 to 420 mm (4 to 16.5 in)
Hs 76 to 364 mm (3 to 14.3 in) 76 to 420 mm (3 to 16.5 in)
Ls 5.08 to 32 mm (0.2 to 1.26 in) 5.08 to 38 mm (0.2 to 1.5 in)
