4-20
Using Set-Up Mode
MACRO 1 and
MACRO 2 Options Values Description
=DEC DEFLTS========= The following are the Set-Up options for DEC PPL2
protocol only.
<DEC PRT ID> Specify the printer ID to be given in response to DA
commands from the computer.
LA50 ID
LA120 ID
LA210 ID
<AUTO WRAP> TRUNCATE Characters are received but not stored in the print
buffer.
WRAP End-of-line wrap. Causes a Carriage Return plus a
Line Feed.
<EOT DISCON> Specify whether the DSR signal is controlled by the
EOT character. (DEC-423 serial interface only)
NO DISCON EOT character is ignored.
DISCONNECT DTR signal turns low for five seconds when the EOT
character is detected.
<INIT REPRT> Specify whether the status is sent to the computer
when the printer is turned on. (DEC-423 serial
interface only)
NO Status is not sent.
YES Status is sent.
<AUTO ANSBK> Specify whether the ANSWERBACK message is sent
to the computer when printer is turned on.
NO ANSWERBACK message is not sent.
YES ANSWERBACK message is sent.
<ANSWER ENQ> Specify whether the ANSWERBACK message is sent
to the computer when printer receives an ENQ code.
NO ANSWERBACK message is not sent.
YES ANSWERBACK message is sent.
(DEC Defaults)
(DEC Printer ID)
(End of Transmis-
sion Disconnect)
(Initialization
Report)
(Automatic
ANSWERBACK)
(ANSWERBACK
on ENQ)
