4-27
Using Set-Up Mode
INSTALL
Options Values Description
<BUFFER>
Assign buffer memory as the input buffer.
2 KBYTE 2K bytes
8 KBYTE 8K bytes
16 KBYTE 16K bytes
32 KBYTE 32K bytes
64 KBYTE 64K bytes
Note:
The larger the input buffer selected, the smaller the
download buffer reduced. Even with 64K bytes of
input buffer, a minimal download buffer is
provided. If you need a larger capacity for
downloading fonts, reduce the input buffer.
<I/F TYPE> Select the type of interface to the computer.
PARALLEL Centronics parallel interface
SERIAL DEC-423 serial interface
AUTO Both interfaces are ready for communication. The
printer communicates with the interface from which it
first receives data. The interface is active until the
input buffer becomes empty.
<AUTO SW> Specify the timing of regarding the selected protocol
or interface as being inactive when AUTO is specified
in the <PROTOCOL> or <I/F TYPE> option.
2 SEC 2 seconds elapsed after data stops from the computer.
4 SEC 4 seconds elapsed after data stops from the computer.
6 SEC 6 seconds elapsed after data stops from the computer.
8 SEC 8 seconds elapsed after data stops from the computer.
10 SEC 10 seconds elapsed after data stops from the computer.
12 SEC 12 seconds elapsed after data stops from the computer.
14 SEC 14 seconds elapsed after data stops from the computer.
16 SEC 16 seconds elapsed after data stops from the
computer.
18 SEC 18 seconds elapsed after data stops from the
computer.
20 SEC 20 seconds elapsed after data stops from the
computer.
(Interface Type)
(Auto Switch)
