Maintenance and Supplies 8-5
Maintenance and Supplies
Loading Paper
When a paper tray is empty, a message displays in the message area
and the tray location flashes on the control panel copier diagram.
MAIN BODY
TRAY 1: Service-adjustable: 250 sheets (20 lb)
TRAY 2: Service-adjustable: 250 sheets (20 lb)
DB-307/607
TRAY 3: Service-adjustable: 1,000 sheets (20 lb)
TRAY 4: Service-adjustable: 250 sheets (20 lb)
Service-Adjustable Tray (Tray 1, 2 and 4)
1 Fan new paper to prevent
paper mishandles.
2 Fully withdraw paper tray from
main body, or drawer base.
3 Push down the bottom T-bar
plate inside the tray until it locks
into place.
4 With curl side up, place paper
in tray from left.
5 Stack paper up to, but not
above, the guide stops located
on the right side of the tray.
NOTE: For best results, store paper on flat surface in cool, dry area. Do not open
paper packages until paper is needed and keep partially used packages tightly
wrapped during storage.
6 While pressing the front guide
knob, move paper guide
against copy paper.
Be sure to insert paper into
slightly below hook level of the
paper tray.
7 Reset the tray into the copier.
