4513/4514 Group User’s Manual
3.6 Mark specification form
3.6 Mark specification form
32P4B (32-PIN SHRINK DIP) MARK SPECIFICATION FORM
Mitsubishi IC catalog name
Please choose one of the marking types below (A, B, C), and enter the Mitsubishi IC catalog name and the special mark (if needed).
A. Standard Mitsubishi Mark
Note1 : If the Special Mark is to be Printed, indicate the desired layout of the mark in the upper figure. The layout will be duplicated as
close as possible. Mitsubishi lot number (6-digit or 7-digit) and Mask ROM number (3-digit) are always marked.
2 : If the customer’s trade mark logo must be used in the Special Mark, check the
box on the right. Please submit a clean original of the logo. For the new special
character fonts a clean font original (ideally logo drawing) must be submitted.
3 : The standard Mitsubishi font is used for all characters except for a logo.
Special logo required
Mitsubishi IC catalog name
C. Special Mark Required
B. Customer’s Parts Number + Mitsubishi catalog name
Customer’s Parts Number
Note : The fonts and size of characters
are standard Mitsubishi type.
Mitsubishi IC catalog name
Note1 : The mark field should be written right aligned.
2 : The fonts and size of characters are standard Mitsubishi type.
3 : Customer’s Parts Number can be up to 16 characters : Only 0 ~ 9, A ~ Z, +, –, /, (, ), &, ,
.
(periods), and
,
(commas) are usable.
4 : If the Mitsubishi logo is not required, check the box on the right.
Mitsubishi logo is not required
