4513/4514 Group User’s Manual
HARDWARE
1-65
LIST OF INSTRUCTION FUNCTION (continued)
Mnemonic
TK0A
TAK0
TPU0A
TAPU0
TFR0A*
TABSI
TSIAB
TAJ1
TJ1A
SST
SNZSI
Function
(K0) ← (A)
(A) ← (K0)
(PU0) ← (A)
(A) ← (PU0)
(FR0) ← (A)
(A) ← (SI3–SI0)
(B) ← (SI7–SI4)
(SI3–SI0) ← (A)
(SI7–SI4) ← (B)
(A) ← (J1)
(J1) ← (A)
(SIOF) ← 0
Serial I/O starting
(SIOF) = 1 ?
After skipping
(SIOF) ← 0
Mnemonic
TABAD
TALA
TA DA B
TAQ1
TQ1A
ADST
SNZAD
TAQ2
TQ2A
NOP
POF
EPOF
SNZP
WRST
TAMR
TMRA
TAQ3
TQ3A
Function
(A) ← (AD5–AD2)
(B) ← (AD9–AD6)
However, in the com-
parator mode,
(A) ← (AD3–AD0)
(B) ← (AD7–AD4)
(A) ← (AD1, AD0, 0, 0)
(AD3–AD0) ← (A)
(AD7–AD4) ← (B)
(A) ← (Q1)
(Q1) ← (A)
(ADF) ← 0
A-D conversion starting
(ADF) = 1 ?
After skipping
(ADF) ← 0
(A) ← (Q2)
(Q2) ← (A)
(PC) ← (PC) + 1
RAM back-up
POF instruction valid
(P) = 1 ?
(WDF1) ← 0, (WEF) ← 1
(A) ← (MR)
(MR) ← (A)
(A) ← (Q3)
(Q33, Q32) ← (A3, A2)
(Q31) ← (CMP1 com-
parison result)
(Q30) ← (CMP0 com-
parison result)
Serial I/O control operation
Input/Output operation
Other operation
A-D conversion operation
*: The 4513 Group does not have these instructions.
Group-
ing
Group-
ing
LIST OF INSTRUCTION FUNCTION
