Table B-27. EM430F5137RF900 Bill of Materials (continued)
No. per Manufacturer's
Item Reference Description Value Manufacturer Comment
Board Part Number
RESISTOR/JUMPER, SMT, 0402, 0
24a R7 1 0Ω ERJ-2GE0R00X PANASONIC
Ω, 5%, 1/16W
RESISTOR, SMT, 0402, THICK
25 R2-R3, R6 3 330Ω ERJ-2GEJ331 PANASONIC
FILM, 5%, 1/16W, 330
CAPACITOR, SMT, 0402, CER,
26 C431, C441 0 12pF ECJ-0EC1H120J PANASONIC
12pF, 50V, 5%, NPO
CAPACITOR, SMT, 0402, CER, 0.0022u
27 C401 1 ECJ-0EB1H222K PANASONIC
2200pF, 50V, 10%, X7R F
RESISTOR, SMT, THICK FILM, 56K,
28 R331 1 56kΩ ERJ-2GEJ563 PANASONIC
1/16W, 5%
C081, C221, CAPACITOR, SMT, 0603,
29 4 10uF ECJ-1VB0J106M PANASONIC
C411, C451 CERAMIC, 10uF, 6.3V, 20%, X5R
RESISTOR/JUMPER, SMT, 0402, 0
30 R1 1 0Ω ERJ-2GE0R00X PANASONIC
Ω, 5%, 1/16W
UNINSTALLED CAP CERAMIC
31 C041 0 4.7uF ECJ-1VB0J475K Panasonic DNP
4.7UF 6.3V X5R 0603
ROSENBERG
32 X1 1 SMA STRIGHT JACK, SMT 32K10A-40ML5
ER
33 Q2 0 Crystal, SMT, 32.768 kHz 32.768k MS3V-T1R Micro Crystal DNP
DUT, SMT, PQFP, RGZ-48,
34 U1 1 0.5mmLS, 7.15x7.15x1mm, CC430F52x1 TI
THRM.PAD
35 JP1 1 Pin Connector 2x4pin 61300821121 WUERTH
CON1-
36 0 Pin Connector 2x4pin 61300821121 WUERTH DNP
CON9
37 JP2 1 Pin Connector 1x3pin 61300311121 WUERTH
JP3, JP5,
38 3 Pin Connector 1x2pin 61300211121 WUERTH
JP10
38a JP7, CON13 0 Pin Connector 1x2pin 61300211121 WUERTH DNP
39 JP4 1 Pin Connector 2x2pin 61300421121 WUERTH DNP
40 JP1a 1 Pin Connector 2x3pin 61300621121 WUERTH
115
