MSP-TS430PW24
Table B-5. MSP-TS430PW24 Bill of Materials
No. per
Position Ref Des Description DigiKey Part No. Comment
Board
1 C1, C2 0 12pF, SMD0805 DNP
2 C5 1 2.2nF, SMD0805
3 C3, C7 2 10uF/10V, SMD0805
4 C4, C6, C8 3 100nF, SMD0805 478-3351-2-ND
5 D1 1 green LED, SMD0805 P516TR-ND
DNP: Headers and receptacles
"SAM1029-07-
6 J1, J2 0 12-pin header, TH enclosed with kit. Keep vias free of
NDSAM1213-07-ND"
solder. (Header & Receptacle)
J5, JP1,
JP4, JP5, Place jumper on 1-2 of JP4-JP9
7 8 3-pin header, male, TH SAM1035-03-ND
JP6, JP7, Place on 1-2 on JP1
JP8, JP9
8 JP2, JP3 2 2-pin header, male, TH SAM1035-02-ND Place jumper on header
9 9 Jumper 15-38-1024-ND see Pos 7 an 8
14-pin connector, male,
10 JTAG 1 HRP14H-ND
TH
11 Q1 0 Crystal DNP: keep vias free of solder
12 R1, R7 2 330 Ω, SMD0805 541-330ATR-ND
R5, R6,
13 2 0 Ohm, SMD0805 541-000ATR-ND DNP R5, R6
R8, R9,
14 R4 1 47k Ohm, SMD0805 541-47000ATR-ND
Socket: OTS
15 U1 1 Manuf.: Enplas
24(28)-065-02-00
16 PCB 1 68.5 x 61 mm 2 layers
Adhesive about 6mm width, 2mm e.g., 3M Bumpons Part
17 4 Apply to corners at bottom side
plastic feet height No. SJ-5302
18 MSP430 2 MSP430AFE2xx DNP: enclosed with kit, supplied by TI
45
