June 2005 © TOSHIBA TEC e-STUDIO281c/351c/451c ERROR CODE AND SELF-DIAGNOSTIC MODE
2 - 119
2
486 Laser Timing of auto-clearing of
polygonal motor pre-run-
ning rotation
ALL 0
<0-2>
SYS Switches the polygonal
motor to the standby
rotation when a certain
period of time has
passed from the pre-
running. At this code,
the period to switch the
status to the standby
rotation is set.
0: 15 sec.
1: 30 sec.
2: 45 sec.
* This setting is effec-
tive when “0” or “2”
is set at 08-483.
1
487 Transfer Selection of performing the
2nd transfer roller cleaning
(Bypass feed)
ALL 0
<0-1>
M 0: Performs only at no
paper size is desig-
nated
1: Performs regardless
of designation of
paper size
1
488 Laser Setting of polygonal motor
type
ALL 3
<2-3>
M Set the type of polygo-
nal motor.
2: 2 clock type
3: 3 clock type
1
489 Laser Polygonal motor rotation
number on standby
ALL 5
<0-5>
M 0: 38090.55rpm
1: 35000rpm
2: 30000rpm
3: 25000rpm
4: 20000rpm
5: 10000rpm
1
490 Laser Polygonal motor rotation in
the energy saving mode
ALL 0
<0-1>
M 0: Stopped
1: 10000rpm.
1
497 General Speed switching for color
printing
ALL
(color)
0
<0-1>
M Sets the speed for color
printing.
0: 11 pages/minute
1: 6 pages/minute
1
502 Image Error diffusion and dither
setting at photo mode
PPC
(black)
0
<0-1>
SYS Sets the image repro-
duction method at
photo mode.
0: Error diffusion
1: Dither
1
503 User
interface
Default setting of density
adjustment
PPC
(black)
0
<0-1>
SYS 0: Automatic
1: Manual (Center)
1
511 Main
charger
Main charger wire auto-
cleaning setting
ALL 1
<0-1>
M 0: Invalid
1: Valid
1
526-0 Fuser Pre-running time for first
printing
(OHP film)
ALL
(black)
16
<0-16>
M 0: Invalid 1: 0 sec.
2: 2 sec. 3: 3 sec.
4: 4 sec. 5: 5 sec.
6: 6 sec. 7: 7 sec.
8: 8 sec. 9: 10 sec.
10: 12 sec.
11: 14 sec.
12: 16 sec.
13: 18 sec.
14: 20 sec.
15: 25 sec.
16: 30 sec.
4
526-1 ALL
(color)
0
<0-16>
M4
Setting mode (08)
Code
Classifi-
cation
Items
Func-
tion
Default
<Accept-
able
value>
RAM Contents
Pro-
cedur
e
