5.1.4 Other paper jam
[E030] Power-ON jam
Relation between the jamming area and the corresponding sensors/covers.
(If a jam is occurring in the ADU, LCF or PFP, check the board in each unit.)
[E061] Incorrect paper size setting for upper drawer
[E062] Incorrect paper size setting for lower drawer
[E063] Incorrect paper size setting for PFP upper drawer
[E064] Incorrect paper size setting for PFP lower drawer
[E065] Incorrect paper size setting for bypass tray
Open the cover of the unit/area whose picture is flashing on the control panel.
Is there any paper on the transport path? (Refer to the following table)
È
YES Æ Remove the paper.
NO
Is the sensor in the jamming area working?
(Perform the input check: Refer to the following table.)
|
|
|
|
|
|
|
|
|
È
NO Æ 1) Check if the connector of the sensor is disconnected.
2) Check if any of the connectors on the LGC board is disconnected.
3) Check if the connector pins are disconnected or the harnesses are open
circuited.
4) Check if the conductor pattern on the LGC board is short circuited or open
circuited.
5) Replace the sensor.
6) Replace the LGC board.
NO
Replace the LGC board.
Jamming area Cover Sensor Test Mode/Input check
Registration area Jam access cover Registration sensor 03-[FAX]ON/[9]/[E]
Upper drawer feed sensor 03-[FAX]ON/[3]/[H]
Exit area Fuser cover Exit sensor 03-[FAX]OFF/[7]/[H]
ADU ADU ADU entrance sensor 03-[FAX]OFF/[8]/[H]
ADU exit sensor 03-[FAX]OFF/[8]/[G]
Feeding area
(equipment)
Side cover Lower drawer feed sensor 03-[FAX]ON/[3]/[G]
Bypass unit Bypass unit Bypass feed sensor 03-[FAX]ON/[9]/[D]
LCF LCF side cover LCF feed sensor 03-[FAX]OFF/[5]/[G]
PFP PFP side cover PFP upper drawer feed sensor 03-[FAX]OFF/[2]/[D]
PFP lower drawer feed sensor 03-[FAX]OFF/[4]/[D]
Bridge unit Bridge unit Bridge unit transport sensor-1 03-[FAX]ON/[0]/[C]
Bridge unit transport sensor-2 03-[FAX]ON/[0]/[A]
If any paper remains in the equipment or drawer, remove it. Match the paper size of the
drawer setting and the one in the drawer.
* Paper size detection is performed at the first sheet of paper when the drawer is opened
or closed, or when the power of the equipment is turned ON.
