June 2005 © TOSHIBA TEC e-STUDIO281c/351c/451c ERROR CODE AND SELF-DIAGNOSTIC MODE
2 - 193
2
Cleaning roller 1260-0 to 8 1261 <Default values of code 1260
(e-STUDIO281c/351c/451c)>
Sub-codes 0, 2, 3, 5, 6, 7, 8: 0/0/0
Sub-code 1: 100,000/120,000/
150,000
Sub-code 4: 285,000/285,000/
285,000
Pressure roller separation
finger
1270-0 to 8 1271 <Default values of code 1270
(e-STUDIO281c/351c/451c)>
Sub-codes 0, 2, 3, 5, 6, 7, 8: 0/0/0
Sub-code 1: 100,000/120,000/
150,000
Sub-code 4: 285,000/285,000/
285,000
Fuser belt 1272-0 to 8 1273 <Default values of code 1272
(e-STUDIO281c/351c/451c)>
Sub-codes 0, 2, 3, 5, 6, 7, 8: 0/0/0
Sub-code 1: 100,000/120,000/
150,000
Sub-code 4: 285,000/285,000/
285,000
Fuser belt guide 1276-0 to 8 1277 <Default values of code 1276
(e-STUDIO281c/351c/451c)>
Sub-codes 0, 2, 3, 5, 6, 7, 8: 0/0/0
Sub-code 1: 100,000/120,000/
150,000
Sub-code 4: 285,000/285,000/
285,000
Pickup roller
(RADF)
1282-0, 1, 2, 8 1283 <Default values of code 1282
(e-STUDIO281c/351c/451c)>
Sub-codes 0, 2, 8: 0/0/0
Sub-code 1: 120,000/120,000/
120,000
Feed roller
(RADF)
1284-0,1,2,8 1285 <Default values of code 1284
(e-STUDIO281c/351c/451c)>
Sub-codes 0, 2, 8: 0/0/0
Sub-code 1: 120,000/120,000/
120,000
Separation roller
(RADF)
1286-0, 1, 2, 8 1287 <Default values of code 1286
(e-STUDIO281c/351c/451c)>
Sub-codes 0, 2, 8: 0/0/0
Sub-code 1: 120,000/120,000/
120,000
Pickup roller
(Upper drawer)
1290-0, 1, 2, 8 1291 <Default values of code 1290
(e-STUDIO281c/351c/451c)>
Sub-codes 0, 2, 8: 0/0/0
Sub-code 1: 80,000/80,000/80,000
Pickup roller
(Lower drawer)
1292-0,1,2,8 1293 <Default values of code 1292
(e-STUDIO281c/351c/451c)>
Sub-codes 0, 2, 8: 0/0/0
Sub-code 1: 80,000/80,000/80,000
Pickup roller
(LCF)
1294-0,1,2,8 1295 <Default values of code 1294
(e-STUDIO281c/351c/451c)>
Sub-codes 0, 2, 8: 0/0/0
Sub-code 1: 160,000/160,000/
160,000
Items
PM management set-
ting <Procedure 4>
*Indicated in 8 digits
Date of previous
replacement
<Procedure 2>
Remarks
