6. TERMINAL FILE PROGRAMMING
EO3-11106
6.16 Display item Name Programming
6-85
3) Example
To program “BALANCE DUE” instead of standard program data “TOTAL” for Item Code 3.
Operation LCD Display Remarks
When the ECR is being outside a sale
and in SET mode, depress the [↓] key.
The cursor is moved on to “2 NAMES”.
Depress the [2] or [Enter] key.
“2 NAMES” is selected.
Depress the [↓] key seven times.
The cursor is moved on to
”8 DISPLAY ITEM NAME”.
Depress the [8] or [Enter] key.
”8 DISPLAY ITEM NAME” is selected.
Depress the [↓] key twice, then
depress the [Enter] key.
(Item code 3 (“TOTAL”) is selected.)
While ? is shown on the upper-right corner
of the LCD display screen, the [?] key
depression results in that the following
guidance message appears on the LCD
display.
The [C] key depression clears the
display item name already
programmed.
The display item name already programmed
is displayed.
Input a desired name.
Numbers of programmed characters and of
programmable characters are displayed on
the 7-segment numeric display.
Example of key operation)
[B] [A] [L] [A] [N] [C] [E] [→] [D] [U] [E]
[Enter]
The [Enter] key depression results in
that the input name is entered and
displayed.
When the [Enter] key is depressed, the
programmed data is printed.
(continued on the next page)
