6. TERMINAL FILE PROGRAMMING
EO3-11106
6.11 Cashier Name and Status Programming
6-63
6.11 Cashier Name and Status Programming
Cashier Name and Cashier Status for each cashier can be programmed here.
Any time outside a sale
Mode Lock: SET
1) Menu Tree
2) Operation Flowchart
Main Menu
ECR is being outside a sale and in SET mode.
Depress [↓] then [Enter].
or
Depress [2].
“2 NAMES” for various name programming is selected.
Depress [↓] twice then [Enter].
or
Depress [3].
“3 CASHIER NAME” is selected.
The cashier name already programmed is displayed.
Select a cashier to be programmed
with the [↑] or [↓] key, then depress
[Enter].
The [Enter] key depression allows the ECR to enter the programming
mode for a desired cashier. (Cashiers 1 to 8 are programmable.)
[Enter]
The ECR enters character input mode.
Input a cashier name.
A maximum of 12 one-byte or 6 two-byte characters are input.
[Enter]
The cashier name is entered and displayed.
[Enter]
The ECR enters the cashier status input mode.
Select a cashier status with the [↑] or
[↓] key, then depress the [→] key to
set/reset the status.
The two statuses below are set/reset. (N: Reset, Y: Set)
01 Training
02 All MDR
[Enter]
The programmed data is printed.
[End]
This programming is ended. A long receipt is issued and the display
returns to Main Menu screen.
*
OPERATION
CONDITION
*: Depress the [Rtn] key to program another cashier.
