6. TERMINAL FILE PROGRAMMING
EO3-11106
6.22 Key Sticker Printing
6-112
(2) To print part of department names.
Operation LCD Display Remarks
When the ECR is being outside a sale
and in SET mode, depress the [↓] key
twice.
The cursor is moved on to “3 DP/PLU”.
Depress the [3] or [Enter] key.
“3 DP/PLU” is selected.
Depress the [1] or [Enter] key.
”1 DP” is selected.
Depress the [↓] key three times.
The cursor is moved on to “4 KEY STICKER
PRINT”.
Depress the [4] or [Enter] key.
“4 KEY STICKER PRINT” is selected.
Depress the [↓] key.
The cursor is moved on to “2 INDIVIDUAL
DP”.
Depress the [2] or [Enter] key.
”2 INDIVIDUAL DP” is selected
The department name already
programmed is displayed.
Move the cursor on to a desired
department name of which key sticker
is to be printed with the [↓] or [↑] key,
then depress the [Enter] key.
While ? is shown on the upper-right corner
of the LCD display screen, the [?] key
depression results in that the following
guidance message appears on the LCD
display.
The [End] key depression allows the
ECR to end this operation.
A long receipt is issued and the display
returns to Main Menu screen.
