Troubleshooting IP Multicast Switching (IPMS) Dshell Troubleshooting
OmniSwitch Troubleshooting Guide September 2005 page 14-9
Dshell Troubleshooting
The IPMS application has its own shell to verify the specific data displayed on the CLI. Use a question
mark to display the local list of commands for each level. Every CLI commend has a corresponding output
on this shell with extended information on each entry. See examples below:
Note. Dshell commands should only be used by Alcatel personnel or under the direction of Alcatel.
Misuse or failure to follow procedures that use Dshell commands in this guide correctly can cause lengthy
network down time and/or permanent damage to hardware.
Certified: [Kernel]->ipmsdbg_shell
IPMS Debug Session
type '~' to quit session
MAIN> ?
Main Menu
main - Main Menu
clist - Display Sub-tasks
restart - Restart IPMS
MAIN> clist
Connected Tasks
ipmem
ipmfm
ipmni1 [slot/slice 1/0] [chipset C1] [ONLINE] []
ipmni2 [slot/slice 8/0] [chipset C1] [ONLINE] []
ipmni3 [slot/slice 9/0] [chipset C2] [ONLINE] []
ipmni4 [slot/slice 16/0] [chipset C1] [ONLINE] []
ipmni5 [slot/slice 2/0] [chipset C1] [ONLINE] []
ipmni6 [slot/slice 7/0] [chipset C1] [ONLINE] []
ipmni7 [slot/slice 10/0] [chipset C1] [ONLINE] []
ipmni8 [slot/slice 15/0] [chipset C1] [ONLINE] []
ipmni9 [slot/slice 6/0] [chipset C1] [ONLINE] []
ipmni10 [slot/slice 3/0] [chipset C1] [ONLINE] []
ipmni11 [slot/slice 11/0] [chipset C1] [ONLINE] []
ipmni12 [slot/slice 14/0] [chipset C2] [ONLINE] []
ipmni13 [slot/slice 4/0] [chipset C1] [ONLINE] []
ipmni14 [slot/slice 5/0] [chipset C2] [ONLINE] []
ipmni15 [slot/slice 12/0] [chipset C1] [ONLINE] []
ipmni16 [slot/slice 13/0] [chipset C2] [ONLINE] []
MAIN> ipmem
IPMEM> ?
Current State: Enabled
Hardware Routing: Enabled
Priority: 0
Max Bandwidth: 10
RP Rate Threshold: 65536
PIM CKSUM mode: Header Only
Available Commands:
