Troubleshooting the Switch System Dshell Troubleshooting
OmniSwitch Troubleshooting Guide September 2005 page 1-23
OmniSwitch 6624/6648 Dshell Troubleshooting
One of the important things in OS-6600 is to confirm the stack topology. This can be confirmed using the
command:
Working: [Kernel]->smctx
****************************************************
local_slot=1 * base_mac= 00:d0:95:84:4b:d2 * local_mac=0000 1111 1111 * TYPE_48
* heart_beat=19007
state=SUPERV role=PRIMARY (primary_slot=1 secondary_slot=2) opposite_way=0
nb=7 elements=0x300ff in_loop=1 supervision=ON (check=0x10100 change=0x0)
gport1=0x1a lport1=0x1a status=1 * gport2=0x1b lport2=0x1b status=1
neighbor1 (nb1=7) [0]=0|0 [1]=8|1a [2]=7|1b [3]=6|1a [4]=5|1b [5]=4|1a [6]=3|1b
[7]=2|1a
neighbor2 (nb2=7) [0]=2|1b [1]=2|1b [2]=3|1a [3]=4|1b [4]=5|1a [5]=6|1b [6]=7|1a
[7]=8|1b
topology role [1]=1 [2]=2 [3]=3 [4]=3 [5]=3 [6]=3 [7]=3 [8]=3
topology outport [1]=ff [2]=1b [3]=1b [4]=1b [5]=1a [6]=1a [7]=1a [8]=1a
topology base mac
[2]= 00:d0:95:84:3d:24
[3]= 00:d0:95:86:50:f2
[4]= 00:d0:95:84:49:bc
[5]= 00:d0:95:84:39:bc
[6]= 00:d0:95:84:4a:8e
[7]= 00:d0:95:84:39:f2
[8]= 00:d0:95:84:3c:42
netid [1]=1|1 [2]=0|0 [3]=0|0 [4]=0|0 [5]=0|0 [6]=0|0 [7]=0|0 [8]=0|0
lookup [1]=ff [2]=1b [3]=1b [4]=1b [5]=1b [6]=1b [7]=1b [8]=1a
subrole [1]=2 [2]=4 [3]=7 [4]=7 [5]=7 [6]=7 [7]=6 [8]=5
list [1]=1 [2]=2 [3]=3 [4]=4 [5]=5 [6]=6 [7]=7 [8]=8 [0]=8
hop [0] [1] [2] [3] [4] [5] [6] [7] [8]
[0] -1 -1 -1 -1 -1 -1 -1 -1 -1
[1] -1 0 1 2 3 4 5 6 1
[2] -1 1 0 1 2 3 4 5 6
[3] -1 2 1 0 1 2 3 4 5
[4] -1 3 2 1 0 1 2 3 4
[5] -1 4 3 2 1 0 1 2 3
[6] -1 5 4 3 2 1 0 1 2
[7] -1 6 5 4 3 2 1 0 1
[8] -1 1 6 5 4 3 2 1 0
*****************************************************************
value = 2 = 0x2
This command indicates the role of the local stack.
output definitions
Local slot Local Stack ID.
Base Mac Base Mac Address of this Stack.
