page -18 OmniSwitch Troubleshooting Guide September 2005
debug ip packet
Displays IP debug configuration parameters. This command is generally used only when working with a
field engineer to debug a problem on the switch.
debug ip packet
Syntax Definitions
N/A
Defaults
N/A
Platforms Supported
OmniSwitch 6624, 6648, 7700, 7800, 8800
Usage Guidelines
This command is used to display IP debug configuration parameters. To start IP debugging you must enter
the start keyword.
Examples
-> debug ip packet
packet dump off,
timeout in seconds 0,
output device console,
board all,
ether-type all,
protocol all,
direction in + out,
mcast/bcast on,
format header,
IP address filter
output definitions
packet dump IP debug administrative status (on/off).
timeout in seconds Duration of the debug session, in seconds. (0 = off).
output device Output device for debug information (e.g., file, console).
ether-type Ethernet packet type to debug (e.g., ARP, IP).
protocol Protocol type to debug (e.g., TCP, UDP).
direction Type of traffic to debug incoming (in) or outgoing (out).
mcast/bcast Specifies whether or not to show broadcast/multicast packets.
format Area of the packet to debug (e.g., header, text).
ip address filter Interface to debug.
