Section 11: Hard Disk Caching
AXIS StorPoint CD E100 User’s Manual 109
Automatic Archiving Check the Auto-archive checkbox to automatically archive all discs that will
be inserted into this drive.
Note: ❏ This checkbox only appears if there is a hard disk connected to the
StorPoint CD.
Eject Click to eject a disc. Note that the disc will be ejected even if the disc is
in use or the drive is locked. However, a warning message will be displayed
if you try to eject a disc that is currently in use.
Lock Check the Lock checkbox to lock a drive. At the bottom of the page, you
can click Lock all or Unlock All to affect all the drives simultaneously.
When the drive is locked it cannot be ejected with the eject button on the
physical drive. However, it can still be ejected from the Discs & Drives
page.
Sorting Click Sort to sort the items by Drive or Name, respectively.
Properties Click the Properties icon to display the Properties dialog box where you
can set properties such as sharing options, user limits and access rights. Click
to set the access rights for the disc.
Note: ❏ You can click the Stop Archiving button to immediately interrupt all
current caching jobs. To restart archiving, check the appropriate
Archive/Auto-archive checkbox(es) again.
Shared Drive Click the Properties icon to display the Properties dialog box. Select if you
want to use the access rights and properties of the Disc or the Drive by
checking the appropriate checkbox. By selecting Drive, all discs inserted
into the drive become accessible under the drive’s name and inherit the
drive’s access rights and properties.
Notes: ❏ When a disc is inserted into a shared drive and then is archived, the disc
copies the drive’s access rights but keeps its original name.
❏ When a disc in a shared drive is archived, or if a previously archived disc is
inserted into a shared drive, the drive icon will indicate that the disc in the
drive is not accessible under the drive’s name. This is because the disc is
already archived under its original name.
