Appendix B: Troubleshooting
AXIS StorPoint CD E100 User’s Manual 129
The Front Panel Indicators
The front panel indicators show the status of the StorPoint CD. The indicators
have the following functions:
• Status - Flashes during startup. When the StorPoint CD is ready for use, the
light turns solid green.
• SCSI/Drive - Flashes to indicate activity on the SCSI/IDE bus.
• Network - Flashes to indicate the presence of network traffic.
• Power - Indicates that power is connected to the StorPoint CD. This LED
should always remain lit and is only used to indicate power is present in the
StorPoint CD unit.
Normal Conditions The Power LED is controlled by hardware and is always green when power is
connected. When the system starts running after startup, the Status LED turns
solid green. The SCSI/Drive and Network LEDs are turned off.
This table shows the other front panel indicators under normal conditions:
* Flashing, short interval.
** Flashing, long interval.
Event Status LED SCSI/Drive LED Network LED
Initial power to unit. GREEN GREEN GREEN
Power-up and self-test,
approx. 30 seconds.
GREEN GREEN GREEN
Firmware preparation GREEN
Firmware startup. GREEN *
Startup sequence OK. GREEN
Normal operation. GREEN
Writing to the SCSI/IDE bus. AMBER *
Reading from the SCSI/IDE
bus.
GREEN *
100 Mbit packet arrived. GREEN *
10 Mbit packet arrived. AMBER *
Flash loading in progress. AMBER *
