Appendix A: Parameter List
AXIS StorPoint CD E100 User’s Manual 123
Directory Structure
The StorPoint CD will appear to your system as a file server. Like any other file
server it has a directory structure where files are stored. The directory structure
of the StorPoint CD is outlined below:
The purpose of each folder is explained on the following pages.
The System folder The System folder includes configuration information about the StorPoint CD,
e.g. configuration settings, connected drives, inserted discs, access rights etc. It
contains these subfolders:
• DeviceProperties - Includes one text file for each connected drive, i.e.
CD/DVD-ROM drives and hard disks.
• Flash - When updating the firmware, the file with the latest firmware
version is copied into this subfolder.
• ServerProperties - Includes the configuration parameter list, event log and
statistics files.
• VolumeProperties - When a disc is inserted into a connected drive, a text
file for that disc will be created. If specified, the volume name will be used.
If no volume name has been specified, the volume label will be used instead.
If the disc does not have a volume label, the StorPoint CD will use a unique
eight digit number. If the disc is blank or uses an unknown file system, the
text file will be named
unknown##.txt.
System
Volumes
Root
SYS
DeviceProperties
VolumeProperties
Disc1
....
or
ServerProperties
Disc3
Disc2
Flash
