Appendix A: Parameter List
AXIS StorPoint CD E100 User’s Manual 119
ServerPassword = pass The Supervisor, Administrator or Root user password used for
basically all protocols; i.e. HTTP, NetWare bindery, SMB user-level,
SNMP and FTP. Once written into the configuration file, the
password will not be shown but replaced with eight *’s,
representing the password.
Domain/GroupName = Name of theStorPoint CD workgroup in SMB. If not specified, the
StorPoint CD will appear in the workgroup that comes first in
alphabetical order.
SecurityMode = shareLevel Specifies the security mode used in SMB: userLevel or shareLevel.
NTDomainInstallation = no Set to yes when you want to install the StorPoint CD in an NT
domain.
EnableNBT = yes Enables SMB over NetBIOS/TCP/IP.
NBTscopeID = Defines the NetBIOS scope to which the StorPoint CD belongs.
EnableNetBEUI = yes Enables SMB over NetBIOS/NetBEUI.
NetBEUIFrameType = auto If set to auto, 802.2 or DIX will automatically be selected by
scanning the network. If required, the frame type can also be set to
either 802_2 or dix.
[NFS]
NFSEnable = yes Enables NFS.
DefaultUid = -2 Default user id to be used when authenticating PCNFSD clients.
Disable by setting the parameter to 0 (zero).
PCNFSDAuthentServer = 0.0.0.0 The IP address of the PCNFSD authentication server used for
authenitcating PCNFSD clients. The default 0.0.0.0 disables the
function.
ExportVolumes = yes Enables export of each new disc inserted as a mount point. If you
restore the factory default settings, all the currently inserted discs
will be exported.
LowerNonCase = yes Set to yes to displays non-case sensitive file systems in lower case.
[SNMP]
GetCommunityName = public Specifies the community that has read only access to all supported
SNMP objects except writeCommunity, SupervisorPassword and
ftpPassword. It corresponds to the readCommunity SNMP object.
TrapDestination = 0.0.0.0 Specifies the IP address which SNMP traps are sent to. It
corresponds to the trapAddress SNMP object. Default is 0.0.0.0,
i.e. all SNMP traps are disabled.
TrapCommunityName = public Specifies the community for all generated SNMP traps. It
corresponds to the trapCommunity SNMP object.
SystemContact = Optional entry which should be in plain text and may be used to
show the name of the system contact person.
SystemName = Optional entry which should be in plain text and may be used to
show the name of the location of the system.
SystemLocation = Optional entry which should be in plain text and may be used to
show the name of the location of the system.
AuthenticationTrap = disabled Disables the SNMP authentication failure traps. It corresponds to
the snmpenableAuthenTraps (MIB-II) SNMP object.
[NetWare]
NWEnable = yes Enables NetWare support.
IPXEnable = yes Enables the IPX protocol.
Frame_802_2 = auto Enables the 802.2 frame type.
Frame_802_3 = auto Enables the 802.3 frame type (Ethernet versions only).
Frame_EthernetII = auto Enables the Ethernet II frame type (Ethernet versions only).
Frame_SNAP = auto Enables the SNAP frame type.
NetWareIP_Enable = no Enables NCP over IPX/UDP (NetWare/IP).
NetWareIP_DSS_Server = The IP address of the DSS server.
PureIPEnable = yes Enables NCP over TCP/IP (PureIP).
ServerName = AXIS<nnnnnn>_NW NetWare server name to be presented to the NetWare clients.
Default is AXIS<nnnnnn>_NW where nnnnnn are the last six digits
of the serial number.
InternalNetAddress = nn-nn-nn-nn Internal network address. Default is nn-nn-nn-nn where nnnnnnnn
are the last eight digits of the serial number.
BurstMode = on Enables burst mode.
ShowAllVolumes = yes Shows all drives and discs also at SYS level.
Parameter name Value Description
