PMC 1 Interface Connectors (J11, J12, J13, J14) Connector Pin Assignments
MVME55006E Single-Board Computer Installation and Use (6806800A37D)
75
61 ACK64# +3.3V 62
63 GND NC (MONARCH#) 64
Table 5-8 PMC 1 Connector (J13) Pin Assignments
Pin Signal Signal Pin
1 PCI_RSVD GND 2
3 GND C/BE7# 4
5 C/BE6# C/BE5# 6
7 C/BE4# GND 8
9VIO PAR64 10
11 AD63 AD62 12
13 AD61 GND 14
15 GND AD60 16
17 AD59 AD58 18
19 AD57 GND 20
21 VIO AD56 22
23 AD55 AD54 24
25 AD53 GND 26
27 GND AD52 28
29 AD51 AD50 30
31 AD49 GND 32
33 GND AD48 34
35 AD47 AD46 36
37 AD45 GND 38
39 VIO AD44 40
41 AD43 AD42 42
43 AD41 GND 44
45 GND AD40 46
47 AD39 AD38 48
49 AD37 GND 50
51 GND AD36 52
53 AD35 AD34 54
55 AD33 GND 56
57 VIO AD32 58
59 PCI_RSVD PCI_RSVD 60
Table 5-7 PMC 1 Connector (J12) Pin Assignments (continued)
Pin Signal Signal Pin
