C141-E090-01EN5 - 62
At command issuance (I-O registers setting contents)
1F7
H
(CM) 1 1 1 1 0 0 0 1
1F6
H
(DH)
× × ×
DV xx
1F5
H
(CH)
1F4
H
(CL)
1F3
H
(SN)
1F2
H
(SC)
1F1
H
(FR)
xx
xx
xx
xx
xx
At command completion (I-O registers setting contents)
1F7
H
(ST) Status information
1F6
H
(DH)
× × ×
DV xx
1F5
H
(CH)
1F4
H
(CL)
1F3
H
(SN)
1F2
H
(SC)
1F1
H
(ER)
xx
xx
xx
xx
Error information
(35) SECURITY UNLOCK (F2h)
This command cancels LOCKED MODE.
The host transfers the 512-byte data shown in Table 1.1 to the device. Operation of the device
varies as follows depending on whether the host specifies the master password or user
password.
• When the master password is selected
When the security level in LOCKED MODE is high, the password is compared with the
master password already set. If the passwords are the same, LOCKED MODE is canceled.
Otherwise, the Aborted Command error is returned. If the security level in LOCKED
MODE is set to the highest level, the Aborted Command error is always returned.
• When the user password is selected
The password is compared with the user password already set. If the passwords are the
same, LOCKED MODE is canceled. Otherwise, the Aborted Command error is returned.
If the password comparison fails, the device decrements the UNLOCK counter. The
UNLOCK counter initially has a value of five. When the value of the UNLOCK counter
reaches zero, this command or the SECURITY ERASE UNIT command causes the Aborted
Command error until the device is turned off and then on, or until a hardware reset is
executed. Issuing this command with LOCKED MODE canceled (in UNLOCK MODE) has
no affect on the UNLOCK counter.
Issuing this command in FROZEN MODE returns the Aborted Command error.
