C141-E090-01EN 5 - 95
5.6.3.8 Sustained Ultra DMA data out burst
5.6.3.2 contains the values for the timings for each of the Ultra DMA Modes.
Note:
DD (15:0) and HSTROBE signals are shown at both the device and the host to emphasize
that cable setting time as well as cable propagation delay shall not allow the data signals to
be considered stable at the device until some time after they are driven by the host.
Figure 5.16 Sustained Ultra DMA data out burst
