C141-E090-01EN 1 - 5
1.2.2 Model and product number
Table 1.2 lists the model names and product numbers.
Table 1.2 Model names and product numbers
Model Name
Capacity
(user area)
Mounting
Screw
Order No. Remarks
MPE3102AH 10.24 GB No. 6-32UNC CA05405-B331 —
MPE3136AH 13.66 GB No. 6-32UNC CA05405-B341 —
MPE3204AH 20.49 GB No. 6-32UNC CA05405-B361 —
MPE3273AH 27.32 GB No. 6-32UNC CA05405-B381 —
1.3 Power Requirements
(1) Input Voltage
• + 5 V ±5 %
• + 12 V ±8 %
(2) Ripple
+12 V +5 V
Maximum 200 mV (peak to peak) 100 mV (peak to peak)
Frequency DC to 1 MHz DC to 1 MHz
